Gasket Kit - Yamaha Outboard - 60/70HP 84-15 (6H3W00010200)

Gasket Set - Yamaha Outboard 60/70HP 1984-2015

Replaces OEM:
Yamaha #6H3-W0001-02-00

Kit includes:
Head Gasket 6H3-11181-A0-00 1 506-10
Head Cover Gasket 6H3-11193-A0-00 1 506-11
Base Gasket 6H3-45113-A0-00 1 511-10
Reed Valve Gasket 6H3-13622-A1-00 2 518-10
Carb. Gasket 6H3-14198-01-00 1 518-11
Exhaust Cover Gasket 6H3-41112-A0-00 1 523-10
Exhaust Cover Gasket 6H3-41114-A0-00 1 523-11
Upper Crank O-Ring 93210-46M16-00 1 527-10
Lower Crank O-Ring 93210-65M50-00 1 527-11
Thermostat Cover 6H3-12414-A1-00 1 541-25
Fuel Pump Gasket 650-24431-A0-00 1 541-26
Lower Crank Oil Seal 93102-36M24-00 1 551-10
Upper Crank Oil Seal 93102-30M23-00 1 551-11
Lower Crank Oil Seal 93106-18M01-00 1 551-12
Carb Mounting O-Rings 93210-39me4-00 3 527-14

See Fitment for applications:

Fits Models:

Yamaha C-TLR 60 2000
Yamaha P-TLH 60 1994
Yamaha P-TLH 60 1995
Yamaha P-TLH 60 1996
Yamaha P-TLH 60 1997
Yamaha P-TLH 60 1998
Yamaha P-TLH 60 1999
Yamaha TLR 60 2001
Yamaha TLR 60 2002
Yamaha TLR 60 2003
Yamaha TLR 60 2004
Yamaha TLR 60 2005
Yamaha TLR 60 2006
Yamaha TLR 60 2007
Yamaha TLR 60 2008
Yamaha TLR 60 2009
Yamaha TLR 60 2010
Yamaha TLR 60 2011
Yamaha TLR 60 2012
Yamaha TLR 60 2013
Yamaha TLR 60 2014
Yamaha TLR 60 2015
Yamaha C-TLR 70 2000
Yamaha C-TLR 70 2001
Yamaha TLR 70 1994
Yamaha TLR 70 1995
Yamaha TLR 70 1996
Yamaha TLR 70 1997
Yamaha TLR 70 1998
Yamaha TLR 70 1999
Yamaha TLR 70 2000
Yamaha TLR 70 2001
Yamaha TLR 70 2002
Yamaha TLR 70 2003
Yamaha TLR 70 2004
Yamaha TLR 70 2005
Yamaha TLR 70 2006
Yamaha TLR 70 2007
Yamaha TLR 70 2008
Yamaha TLR 70 2009
Yamaha TLR 70 2010
Yamaha TLR 70 2011
Yamaha TLR 70 2012
Yamaha TLR 70 2013
Yamaha TLR 70 2014
Yamaha TLR 70 2015
